Masibus Automation VMS4SE User Manual

User Manual 65
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
Exceptional Response:
Table 38 Exceptional Response
Byte
Contents
Example
1
Slave Address
0A
2
Function
81 (80 + Function Code From Query)
3
Exceptional Code
02
4
CRC Hi
XX
5
CRC Lo
XX
 Exception Codes
Table 39 Exception codes
CODE
NAME
MEANING
01
Illegal Function
The function code received in the query is not an allowable
action for the slave. If a Poll Program Complete command Was
issued, this code indicates that no Program function preceded
it.
02
Illegal Data Address
The data address received in the query is not an allowable
address for the Slave.
03
Illegal Data Value
A value contained in the query data field is not an allowable
value for the Slave.
10.3 Modbus Addresses
Table 40 Process Value and Status Read Parameters
Sr.
No
Parameter Description
Modbus
Address
Parameter
Type
Access
Remarks
1
Channel – 1 – PV
30001
Integer
R
-
2
Channel – 2 – PV
30002
Integer
R
-
3
Channel – 3 - PV
30003
Integer
R
-
4
Channel – 4 - PV
30004
Integer
R
-
5
Channel – 5 – PV
30005
Integer
R
-
6
Channel – 6 – PV
30006
Integer
R
-
7
Channel – 7 – PV
30007
Integer
R
-
8
Channel – 8 – PV
30008
Integer
R
-
9
Channel – 9 – PV
30009
Integer
R
-
10
Channel – 10 – PV
30010
Integer
R
-
11
Channel – 11 – PV
30011
Integer
R
-
12
Channel – 12 – PV
30012
Integer
R
-
13
Channel – 13 – PV
30013
Integer
R
-
14
Channel – 14 – PV
30014
Integer
R
-
15
Channel – 15 – PV
30015
Integer
R
-
16
Channel – 16 – PV
30016
Integer
R
-
17
Channel – 17 – PV
30017
Integer
R
-
18
Channel – 18 – PV
30018
Integer
R
-
19
Channel – 19 – PV
30019
Integer
R
-
20
Channel – 20 – PV
30020
Integer
R
-
21
Channel – 21 – PV
30021
Integer
R
-
22
Channel – 22 – PV
30022
Integer
R
-
