C.3.4 How to Configure Profibus Vibration Monitor:
1. Start the Application mPCTool.Exe from Program Files
2. At the End of Loading Application software itself will detect the Vibration Monitor
automatically. And start uploading all the stored Parameters of the Vibration Monitor.
3. If module not detect below error message display and if user still wants to enter into
software, user can enter by pressing yes. Now user has to select the parameter by
selecting the project from the open project from file menu.
4. If error not occurs then below screen shows the automatic uploaded parameters from the
Vibration Monitor.
