VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
1.1 Product Ordering Code
The VMS4SE Vibration Monitor unit has a nameplate affixed to the one side of the enclosure. Check
the model and suffix codes inscribed on the nameplate to confirm that the product received is that
which was ordered.
Table 1 Product Ordering code
Table 2 Product Ordering Code description
1-RS485 Serial Port and 1-Ethernet RJ45
2-RS485 Serial Port and 1-Ethernet RJ45
Table 3 Cable Ordering Code and description
For 8 Analog Input 1 Input cable required
For 16 Analog Input 2 Input cable required
For 24 Analog Input 3 Input cable required
For 4 Analog Input 1 Input cable required in
Vibration Input
