Masibus Automation VMS4SE User Manual

User Manual 45
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
Table 17 DO(Digital Output) Mapping Number and its description
Channel
Number
AS1 .
Mapping
DO
number
for ASP1
AS2 .
Mapping
DO
number
for ASP2
CSP.
Mapping
DO
number
for CSP
Watchdog
Mapping
DO
number for
W.D.MP
1
Relay 3
3
Relay 4
4
Relay 1
1
Open
Collector
10
18
2
None
0
Relay 4
4
None
0
3
Relay5
5
Relay6
6
None
0
4
Relay5
5
None
0
None
0
5
Open
Collector 3
11
Open
Collector 4
12
Open
Collector 1
9
6
None
0
None
0
None
0
7
Open
Collector 12
20
Open
Collector 8
16
Open
Collector 15
23
8
Open
Collector 20
28
Open
Collector 12
20
None
0
Note 2:
1) None means no DO(Digital Output) is assigned to particular channel.
2) DO number = 0 represents “None” . DO Number = 1 to 8 represents “Relay No. 1 to Relay
No. 8”. DO number = 9 to 32 represents “Open Collector No. 1 to Open Collector No.
24”.For more details refer Table 18.
3) If one particular DO is mapped to any channel in control set point mapping
(C.S.MP.)configuration, it cannot be mapped to any other channel in any type of mapping( In
above example, Relay-1is mapped to channel number 1in control set point mapping
configuration shown in Table 17. So it cannot be assigned to any other channel in Control set
point mapping (C.S.mp.) or Alarm Set point 1 mapping (A1.MP) or Alarm Set point 2
Mapping(A2.MP) as shown in Table 17.
4) Maximum one channel can be assigned to control set point mapping (C.S.MP) configuration.
In above example, Relay-1 cannot be assigned to any second channel.
5) Same number of DO (other than mapped to control set point mapping) can be mapped to
multiple number of Channels in Alarm set point 1 mapping (A1.MP) and Alarm set point 2
mapping (A2.MP). In above example, Relay 4 is assigned to channel 1 and channel 2 in AS2.
Mapping, Relay 5 is mapped to channel 3 and channel 4 in AS1. Mapping, Open collector
12 is mapped to channel 7 in AS1. Mapping and it is mapped to channel 8 in AS2. Mapping.
6) Based On Watchdog Output (Disable / Enable) selection , Error messages will be shown. i.e.
if Watchdog Output is “disabled” , then no error message will be shown and only Fault LED
will be ON and other operation goes smoothly. When Watchdog Output is “enabled”, then
based on faults, error messages will be displayed and Fault LED will be ON. For more detail
on watchdog operation and error messages, please refer topic 8.4 Watchdog Timer (WDT)
/ Watchdog Output Operation.
7) Any DO can be mapped to W.D.MP (Watchdog Mapping) . Means, that particular DO is used
as Watchdog Output. Note that, any DO which is assigned to A1.MP or A2.MP or C.S.MP
cannot be mapped to W.D.MP and vice versa.
