By pressing Auto / Manual Key after going into the Manual Mode unit comes back to run
mode.
By pressing Enter Alarm Key in run mode, the menu goes into the settings of alarm set point
value.
By pressing Enter Setpoint Key in run mode, the menu goes into the settings of control set
point value(whenever Control Alarm is required). If Control alarm is not required then –n.A.-
(not applicable) message will be displayed.
Other Modes :
For entering in Menu press Menu/Enter key in RUN mode. There are total Four modes in Menu. By
pressing increment or decrement key mode can be changed. To enter into any mode press
Menu/enter key again.
1. Program mode
2. Configuration mode
3. Calibration mode
4. Security Mode
The tables below show the description and menu detail of the all the modes. In general to enter into
any menu Or to edit sub menu, press Menu/Enter key, to change the submenu parameter press
increment or decrement key. To come out from any menu press Esc key.
1) Program Mode :
Pressing MENU key DATA window shows Prog (Prog) message and Parameter window shows
MODE (Mode) message. Press MENU key again PARAMETER window shows pWd (PWD)
message (if and only if password is set then only. Otherwise it will enter into sub menu), press
MENU Key to enter into edit mode of password and then press INCREMENT key or
DECREMENT key to modify the password and then press MENU Key to enter into Program
Mode. DATA window shows ASP.1 (ASP.1) message and PARAMETER window shows prog
(PROG) message. By pressing MENU Key, DATA window shows Set Point-1 Value. Then use
MENU Key to enter into editing mode and use INCREMENT and DECREMENT key to modify
value. OR press INCREMENT key again to change Set-point 1 for Channel 2. After pressing INC
key many times, the message on Channel Window shows al,(AL) which means user can modify
parameters for all channels at once(AL = ALL). ESCAPE KEY is used to come out ASP.1
Table 12 Program Mode Parameters
