Masibus Automation VMS4SE User Manual

User Manual 14
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
B
450 to 1800C
+ 0.1% of instrument range + 1 digit
1C
R
0 to 1750C
S
0 to 1750C
N
-200 to 1300°C
RTD(PT100)
-199.9 to 850.0C
+ 0.1% of instrument range + 1 digit
0.1C
CU53
-210.0 to 210.0°C
NI120
-70.0 to 210.0°C
-10 to 20 mV
-1999 to 9999
counts
+ 0.1% of instrument range + 1 digit
1 Count
0 to 100 mV
4-20mA
0 to 20 mA
0 – 5 V
1 – 5 V
0 – 10V
3.2 Output Specification
3.2.1 Digital Output- Relay
NUMBER OF OUTPUTS
8
PURPOSE
Alarm or trip or control or watchdog output
OUTPUT SIGNAL
Three terminals C , NO and NC
RELAY CONTACT RATING
250 VAC / 30 VDC @ 2A
NO. OF RELAY OPERATION
1 X 10^5 @ rated current
3.2.2 Digital Output- Open Collector(Optional)
NUMBER OF OUTPUTS
24
PURPOSE
Alarm or trip or control or watchdog output
OUTPUT TYPE
transistor open collector output selection)
CONTACT RATING
30 V DC,100 mA
3.2.3 Analog Output- Retransmission Output(Optional) *
NUMBER OF OUTPUTS
8
OUTPUT SIGNAL
0-20 mA, 4-20 mA or 0-5 V, 1-5 V, 0-10 V DC(Voltage or
current outputs are factory settable)
LOAD RESISTANCE
For current output, 550 ohms Max. For Voltage output, Min.
3000 ohms.
OUTPUT ACCURACY
±0.25% of span
Note : * - With Analog Output, CE marking is not applicable/valid.
3.2.4 Buffer Output for Vibration Input
NUMBER OF OUTPUTS
4
OUTPUT IMPEDANCE
< 100 ohms
FREQUENCY RANGE
0.5 Hz to 10KHz
OUTPUT ACCURACY
±0.25% of Full Range
3.3 Programming and Setting
KEYPAD
8-keys (Menu, Escape, Up, Down, A/M, ACK, SET/OP and SET/AL)
tactile membrane keypad provided for modification of all control and
functional parameters.
CONFIGURATION
All Configurable parameters can be set through PC Based software
