Masibus Automation VMS4SE User Manual

User Manual 44
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
(Pv.Lo)
(DO.CONF)
Applicable for 8 Relays
(Optional),24 Open
Collectors (Optional)
(For all 32
DO(Digital Output))
DO(Digital
Output)) (Relay
1-8 and Open
Collector 1-24)
Output(Either
Relay or Open
Collector) is
required
a1.fn
DO.CONF
Alarm 1 Function
ALrm / TRIP
(Alarm / Trip )
0: ALARM
1 : TRIP
0(for all
channel)
-
(A1.Fn)
(DO.CONF)
a1.mp
DO.CONF
Alarm 1 Mapping
See DO(Digital
Output)
Configuration
Refer
Table 17 and
note 2
Any of Digital
Output(Either
Relay or Open
Collector) is
required
(A1.mP)
(DO.CONF)
a1.tp
DO.CONF
Alarm 1 Type
lo/Hi
0 : LOW
1: HIGH
0 (for all
channel)
-
(A1.tP)
(DO.CONF)
a2.fn
DO.CONF
Alarm 2 Function
ALrm / TRIP
(Alarm / Trip )
0: ALARM
1 : TRIP
0(for all
channel)
-
(A2.Fn)
(DO.CONF)
a2.mp
DO.CONF
Alarm 2 Mapping
See DO(Digital
Output)
Configuration
Refer
Table 17 and
note 2
Any of Digital
Output(Either
Relay or Open
Collector) is
required
(A2.mP)
(DO.CONF)
a2.tp
DO.CONF
Alarm 2 Type
lo/Hi
0 : LOW
1: HIGH
0 (for all
channel)
(A2.tP)
(DO.CONF)
CS.mp
DO.CONF
Control Set point
mapping
See DO(Digital
Output)
Configuration
Refer
Table 17 and
note 2
Control Output is
required and Any
of Digital
Output(Either
Relay or Open
Collector) is
required
(CS.mP)
(DO.CONF)
CS.tp
DO.CONF
Control Set point type
lo/Hi
0 : LOW
1: HIGH
0 (for all
channel)
Control Output is
required
(CS.tP)
(DO.CONF)
W.D.op
DO.CONF
Watchdog Output
dsbl/enbl
0 : Disable
1: Enable
Refer
note 2
-
(W.d.oP)
(DO.CONF)
W.D.mp
DO.CONF
Watchdog Mapping
See DO(Digital
Output)
Configuration
Refer
note 2
Any of Digital
Output(Either
Relay or Open
Collector) is
required
(W.d.mP)
(DO.CONF)
DO(Digital Output) Configuration:
Total numbers of relays in VMS4SE are 8 and total number of Open collectors are
24(Optional) . For one channel maximum three numbers of DOs can be assigned. Among them one
DO can only be assigned for control operation and two remaining DOs can be assigned for Alarm/Trip
operation. Below example shows different configuration and different mapping of different DOs to 8
channels.
