Masibus Automation VMS4SE User Manual

User Manual 66
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
23
Channel – 23 – PV
30023
Integer
R
-
24
Channel – 24 – PV
30024
Integer
R
-
25
Ambient PV
30025
Integer
R
-
26
DO(Digital Output) Status– 32bit
30026
Bit
R
Refer Table 42
27
Alarm1 Status– 32bit
30028
Bit
R
Refer Table 43
28
Alarm2 Status – 32bit
30030
Bit
R
Refer Table 44
29
Control Status – 32bit
30032
Bit
R
Refer Table 456
30
Alarm1 Blink Status – 32bit
30034
Bit
R
Refer Table 456
31
Alarm2 Blink Status- 32 bit
30036
Bit
R
Refer Table 45
32
Alarm1 LED status - 32 bit
30038
Bit
R
Refer Table 456
33
Alarm2 LED status - 32 bit
30040
Bit
R
Refer Table 456
34
Log Memory Percentage
30042
Integer
R
Higher Byte for Event
log and Lower Byte
for Periodic Log
35
Total Periodic Records
30043-44
Integer
R
30043 [Higher byte]
30044[Lower Byte]
36
Total Event Records
30045-46
Integer
R
30045 [Higher byte]
30046[Lower Byte]
Table 41 Details of abnormal Conditions of Process Value
Abnormal Value (Integer)
Description
32762
Reserved
32764
Channel Skip
32765
UNDER Value
32766
OVER Value
32767
Channel OPEN Indication
Table 42 DO (Digital Output) Status Register and its bits arrangement
Parameter
DO(Digital Output) Status
DO(Digital Output) Status
Modbus
Address
30026
30027
Bit No.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Description
Open Collector-24
Open Collector-23
Open Collector-22
Open Collector-21
Open Collector-20
Open Collector-19
Open Collector-18
Open Collector-17
-
Open Collector-16
Open Collector-15
Open Collector-14
Open Collector-13
Open Collector-12
Open Collector-11
Open Collector-10
Open Collector-9
Open Collector-8
Open Collector-7
Open Collector-6
Open Collector-5
Open Collector-4
Open Collector-3
Open Collector-2
Open Collector-1
-
Relay-8
Relay-7
Relay-6
Relay-5
Relay-4
Relay-3
Relay-2
Relay-1
\
