Masibus Automation VMS4SE User Manual

User Manual 67
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
Table 43 Alarm 1 Status Register and its bits arrangement
Parameter
Alarm 1 Status
Alarm 1 Status
Modbus
Address
30028
30029
Bit No.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Description
-
-
-
-
-
-
-
-
-
Channel – 24
Channel – 23
Channel – 22
Channel – 21
Channel – 20
Channel – 19
Channel – 18
Channel – 17
Channel – 16
Channel – 15
Channel – 14
Channel – 13
Channel – 12
Channel – 11
Channel – 10
Channel – 9
-
Channel – 8
Channel – 7
Channel – 6
Channel – 5
Channel – 4
Channel – 3
Channel – 2
Channel – 1
Table 44 Alarm 2 Status Register and its bits arrangement
Parameter
Alarm 2 Status
Alarm 2 Status
Modbus
Address
30030
30031
Bit No.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Description
-
-
-
-
-
-
-
-
-
Channel – 24
Channel – 23
Channel – 22
Channel – 21
Channel – 20
Channel – 19
Channel – 18
Channel – 17
Channel – 16
Channel – 15
Channel – 14
Channel – 13
Channel – 12
Channel – 11
Channel – 10
Channel – 9
-
Channel – 8
Channel – 7
Channel – 6
Channel – 5
Channel – 4
Channel – 3
Channel – 2
Channel – 1
 Above mentioned bit arrangement is applicable to other parameters as explained below.
Table 45 Other Status Registers
Parameter
Control Status
Control Status
Modbus
Address
30032
30033
Parameter
Alarm 1 Blink Status
Alarm 1 Blink Status
Modbus
Address
30034
30035
Parameter
Alarm 2 Blink Status
Alarm 2 Blink Status
Modbus
Address
30036
30037
Parameter
Alarm 1 LED Status
Alarm 1 LED Status
Modbus
Address
30038
30039
Parameter
Alarm 2 LED Status
Alarm 2 LED Status
Modbus
Address
30040
30041
