Masibus Automation VMS4SE User Manual

User Manual 73
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
248
ASP2 Function for Channel 24 - 17
(MSB- LSB)
42035 - H
Bit
0
1
R/W
249
ASP2 type for Channel 8 - 1
(MSB- LSB)
42036 - H
Bit
0
1
R/W
Refer Table 61
250
ASP2 type for Channel 16 - 9
(MSB- LSB)
42036 - L
Bit
0
1
R/W
251
ASP2 type for Channel 24 - 17
(MSB- LSB)
42037 - H
Bit
0
1
R/W
252
CSP type for Channel 8 - 1
(MSB- LSB)
42038 - H
Bit
0
1
R/W
Refer Table 61
253
CSP type for Channel 16 - 9
(MSB- LSB)
42038 - L
Bit
0
1
R/W
254
CSP type for Channel 24 - 17
(MSB- LSB)
42039 - H
Bit
0
1
R/W
255
Retransmission Type 1- 2
42040
Integer
0
4
R/W
Refer Table 62
256
Retransmission Type 3 - 4
42041
Integer
0
4
R/W
257
Retransmission Type 5 - 6
42042
Integer
0
4
R/W
258
Retransmission Type 7 - 8
42043
Integer
0
4
R/W
259
Retransmission Direction for
Retransmission 8 - 1 (MSB- LSB)
42044
Bit
0
1
R/W
Refer Table 63
260
Ch - 1 Retransmission Mapping
42501
Integer
0
8
R/W
Refer Table
2021
Refer Table
2021
261
Ch - 2 Retransmission Mapping
42502
Integer
0
8
R/W
262
Ch - 3 Retransmission Mapping
42503
Integer
0
8
R/W
263
Ch - 4 Retransmission Mapping
42504
Integer
0
8
R/W
264
Ch - 5 Retransmission Mapping
42505
Integer
0
8
R/W
265
Ch - 6 Retransmission Mapping
42506
Integer
0
8
R/W
266
Ch - 7 Retransmission Mapping
42507
Integer
0
8
R/W
267
Ch - 8 Retransmission Mapping
42508
Integer
0
8
R/W
268
Ch - 9 Retransmission Mapping
42509
Integer
0
8
R/W
269
Ch - 10 Retransmission Mapping
42510
Integer
0
8
R/W
270
Ch - 11 Retransmission Mapping
42511
Integer
0
8
R/W
271
Ch - 12 Retransmission Mapping
42512
Integer
0
8
R/W
272
Ch - 13 Retransmission Mapping
42513
Integer
0
8
R/W
273
Ch - 14 Retransmission Mapping
42514
Integer
0
8
R/W
274
Ch - 15 Retransmission Mapping
42515
Integer
0
8
R/W
275
Ch - 16 Retransmission Mapping
42516
Integer
0
8
R/W
276
Ch - 17 Retransmission Mapping
42517
Integer
0
8
R/W
277
Ch - 18 Retransmission Mapping
42518
Integer
0
8
R/W
278
Ch - 19 Retransmission Mapping
42519
Integer
0
8
R/W
279
Ch - 20 Retransmission Mapping
42520
Integer
0
8
R/W
280
Ch - 21 Retransmission Mapping
42521
Integer
0
8
R/W
281
Ch - 22 Retransmission Mapping
42522
Integer
0
8
R/W
282
Ch - 23 Retransmission Mapping
42523
Integer
0
8
R/W
283
Ch - 24 Retransmission Mapping
42524
Integer
0
8
R/W
284
Retransmission Value for
Retransmission 8 - 1 (MSB- LSB)
42057
Bit
0
1
R/W
Refer Table 64
285
Retransmission Open Sensor for
Retransmission 8 - 1 (MSB- LSB)
42058
Bit
0
1
R/W
Refer Table 57
286
Machine ID
42059
Integer
1
247
R/W
-
287
Baud Rate COM 1
42060
Integer
0
1
R/W
Refer Table 65
288
Parity COM1
42061
Integer
0
2
R/W
Refer Table 66
