Masibus Automation VMS4SE User Manual

User Manual 85
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
 RETRAMISSION OUTPUT TABLE FOR OPEN /OVER /UNDER CONDITION (Optional):
Table 75 Retransmission Output during Open/Over/Under Condition
RETRASMISSIO
N
VARIABLE
SCALE
ACTION
OPEN
OVER
UNDER
ERROR
4-20mamp
PV
UP
DIR
20.8
20.8
3.2
-
PV
DOWN
REV
20.8
3.2
20.8
-
PV
UP
REV
3.2
3.2
20.8
-
PV
DOWN
DIR
3.2
20.8
3.2
-
NOTE: - 1) For Retransmission output type 0-20mamp, 0-10v, 1-5v and 0-5v also applicable
according to above table.
2) Also, 0-20mamp, 0-10v and 0-5v minimum output value will be 0mamp and 0v
respectively.
