Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 87 Masimo
Device Output
See Device Output on page 96.
Localization
Use the Localization screen to view the current date and time and configure settings related
to local time, language and geography. The user can also access the Localization screen by
pressing the current time on the Status Bar. See About the Status Bar on page 49.
Option Description Factory Default
Settings
User Configurable
Settings
Language
Select the language display
for Rad-97.
English
Choose from available
languages.
Date Format
Set the display format for
current date.
mm/dd/yy mm/dd/yy or dd/mm/yy
Time Format
Set the display format for
current time.
12 hour 12 or 24 hour
Line
Frequency
Set to match regional power
line frequency.
60 Hz 50 Hz or 60 Hz
Date Set the current date. N/A month, date, and year
Time Set the current time. N/A
hour and minutes
AM or PM

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
