Contender Front Loader
Operation
2.2.2 LED Indicator Light Functions
The LED indicator lights are used to display the status of
various functions and operations (Figure 15). When the
ignition switch is rst turned on, the lights will perform a self-
test which will light all the lights for a few seconds.
No. Position Normal Use or Reading
1 Pump On LED
The LED will be green when the
pump is on.
2
Error Code
LED
There are six LEDs that will be on
or off depending on the error code.
If any of these LEDs are lighted,
refer to the error code decal located
on the cab center console. Note: To
enter the diagnostic mode, press
and hold both buttons with the
exclamation icon for ve seconds.
3
Tailgate Closed
LED
The LED will be green when the
tailgate is fully closed. The LED will
ash red when the tailgate is in the
process of being closed.
4
Tailgate Open
LED
The LED will ash red if the tailgate
is not fully closed.
No. Position Normal Use or Reading
5 Activate LED
If a button is pressed that requires
the ACTIVATE button to be pressed,
but the ACTIVATE button was not
pressed, the amber LED will ash,
indicating the ACTIVATE button
must also be pressed.
6
Top Door Open
LED
The LED will be green when the top
door is fully open.
7
Top Door Close
LED
The LED will ash red when the top
door is in the fully closed position.
8 Side Door LED
When the side door is fully closed,
the LED will be off.
When the side door is opened, it
activates the E-STOP, shuts off the
hydraulic pump, and the red LED
will ash. The hydraulic pump icon
and the amber LED above it will
also ash.
9 AutoPack LEDs
The two red LEDs will ash when
the pack/eject is in the autopack
mode.
10
Pack/Eject
Retract LED
The LED will be green when the
pack/eject is retracted into the
HOME position.
