McNeilus Contender - 3.5 Auto Dump Functions (Optional)

63
© 2013 McNeilus Truck and Manufacturing, Inc.
Contender Front Loader
Operation
3.5 Auto Dump Functions (Optional)
With the Auto Dump Function, the fork assembly is
automatically rotated when the arm assembly is raised or
lowered. The fork assembly is rotated to avoid interference
with the body canopy.
Be sure all non-operator personnel are at
least 20 feet (6 meters) away from all areas
of the Packer.
Serious personal injury or death may occur.
WARNING
Make sure the area above the vehicle is
clear of objects and power lines before
raising the arm.
Serious personal injury or death may occur.
DANGER
CAUTION
Use caution when raising the arm assembly
with a container.
Conditions
• Side door indicator light must be off
• Top Door OPEN indicator light must be green
• Pack/Eject RETRACT indicator light must be green
• Engine speed must be below 1600 rpm
After the forks are positioned in the container, follow the
procedure for Auto Dump controls on your refuse vehicle (see
2.3.5 Auto Dump Single Lever).
1. Turn on pump.
2. Turn on Residential Mode.
3. Pull and hold the joystick straight back.
4. The arm assembly will begin to raise with the container
(Figure 30, Item 1).
5. As the arm assembly raises above the body (cab), the
fork assembly will automatically lower to a level position
(Figure 30, Item 2).
6. The arm assembly will start to raise until the fork
assembly is fully raised and the container is in the DUMP
position (Figure 30, Item 3).
7. Push and hold forward once load is dumped to lower can.
8. After the container is emptied, the fork assembly will
begin to lower until the container is out of the hopper.
9. After the fork assembly stops, the arm assembly will
begin to lower and place the container on the ground.
