Contender Front Loader
3.4 Fork Functions
The Fork Functions are controlled from the chassis cab or
outside control box.
Be sure all non-operator personnel are at
least 20 feet (6 meters) away from all areas
of the Packer.
Serious personal injury or death may occur.
WARNING
Make sure the area above the vehicle is
clear of objects and power lines before
raising the arm.
Serious personal injury or death may occur.
DANGER
Conditions
• Side door indicator light must be off
• Engine speed must be below 1600 rpm
Use the fork controls to raise the fork assembly (Figure 29,
Item 1).
Use the fork controls to lower the fork assembly (Figure 29,
Item 2).
Operation
2
1
Figure 29
