Contender Front Loader
Operation
3.2.3 Manual Cycling with Tailgate Open
Conditions
(Applies to Extend Function Only)
• Side door indicator light must be off
• Top Door OPEN indicator light must be green
• Tailgate must be fully open
• Engine speed must be below 1600 rpm
When the tailgate is OPEN, the EXTEND button or the
RETRACT button controls the Pack/Eject Functions, however,
the pack/eject can travel into the body.
With the tailgate fully OPEN, the pack/eject will extend past
the EXTEND position. The distance that the pack/eject
extends into the body is determined by holding the EXTEND
button.
While holding the EXTEND button, the pack/eject (Figure 27,
Item 1) will extend to the rear of the body to eject the load.
Press and hold the RETRACT button to retract the pack/eject
to the HOME position.
Figure 27
1
