112 MDS iNET 900 User’s Guide MDS 05-2806A01, Rev. A
6.3 MDS iNET 900 TECHNICAL
SPECIFICATIONS
GENERAL
Temperature Range: –30° C to +60° C (–22° F to 140° F)
Humidity: 95% at +40° C (104° F); non-condensing
Primary Power: 10.5–30 Vdc (13.8 Vdc Nominal)
External Power Supply Options: 110–120/210–220 Vac
Supply Current (typical): (8 Watts Maximum @ 1 Watt RF Output)
Transmit: 580 mA @ 13.8 Vdc
Receive: 203 mA @ 13.8 Vdc
MTBF: 35 Years (Telcordia Method 1, Case 3)
Size (Excluding mtg. hardware): 1.5" x 6" x 4" (H x W x D)
3.8 x 15.2 x 10.2 cm
Mounting w/Optional Hardware: • Flat surface mounting brackets
• 19” rack (1U high)
Weight: 0.9 kg / 2 lb
Case: Cast Aluminum
Boot Time: ≈ 30 sec
Time Required to Associate
with Access Point: ≈ 20 sec
APPROVALS/HOMOLOGATION
• FCC Part 15.247
E5MDS-NH900
• Industry Canada RSS-210 and RSS-139
CAN 3738A 12098
• UL/FM Class 1, Div. 2; Groups A, B, C and D
hazardous locations (Pending)
• UL Listed (Pending)
• Contact MDS for information on availability and
governmental approvals in other countries
EMBEDDED MANAGEMENT SYSTEM
• HTTP (Embedded Web server)
• Text-based menu on COM1 serial port
• Telnet
DATA CHARACTERISTICS
PORTS:
Ethernet:
Interface Connectors: RJ-45 Standard
Data Rate: 10BaseT
Serial (2 Ports):
