46 MDS iNET 900 User’s Guide MDS 05-2806A01, Rev. A
Packet Statistics Menu
Figure 2-25. Sample Packet Statistics Menu Screen
Wireless Packet
Statistics
• Packets received—Over-the-air data packets received by
this unit
• Packets sent—Over-the-air data packets sent by this
Remote.
• Bytes received—Over-the-air data bytes received by this
Remote.
• Bytes sent—Over-the-air data bytes sent by this Remote.
• Packets dropped—Received packets dropped as a result of
a lack of buffers.
• Receive errors—Packets that do not pass CRC. This may
be due to transmissions corrupted by RF interference.
• Retries—Number of requests to re-send a data packet
• Retry errors—Packets discarded after exceeding five
retries over-the-air.
• Clear Wireless stats—Initiates resetting of the statis-
tics counter.
Ethernet Packet
Statistics
• Packets received—Packets received by the iNET through
the Ethernet port.
• Packets sent—Packets received by the iNET through the
Ethernet port.
• Bytes received—Data bytes received by this Remote.
• Bytes sent—Data bytes sent by this Remote.
• Packets dropped—Received packets dropped as a result of
a lack of buffers.
• Receive errors—Packets discarded after exceeding five
retries the network.
• Lost carrier detected—A count of how many times the
carrier signal on the Ethernet port has been missing. This count
increase significantly when the Ethernet cable is plugged in and
unplugged.
Library Admin Office
Packet Statistics Menu
-==========================================================================-
Wireless Packet Statistics Ethernet Packet Statistics
Packets received 2206 Packets received 0
Packets sent 2177 Packets sent 2172
Bytes received 247575 Bytes received 0
Bytes sent 236106 Bytes sent 161877
Packets dropped 0 Packets dropped 0
Receive errors 1 Receive errors 0
Retries 4 Lost carrier detected 0
Retry errors 2
A) Clear Wireless stats B) Clear Ethernet stats
Select a letter to configure an item, <ESC> for the prev menu
