COM1/2—Serial Gateway Configuration Screen—
IP-to-Serial Mode
Figure 2-13. COM1/2—Serial Gateway Configuration Screen
(with IP-to-Serial Mode enabled)
• Enable—Enable/Disable the serial data port.
NOTE: Setting this parameter for COM1 port to Enable pro-
hibits access of the iNET Management System through this
port. However, the iNET MS can still be accessed via Telnet
or browser through the LAN port.
• Mode—Select IP-to-Serial or Serial-to-Serial.
• Data Baud Rate—Data rate for the
COM port.
1,200–115,200 bps.
• Flow Control—RTS/CTS handshaking between iNET
and connected device. (Enable/Disable)
• Receive on Port—Receive IP data from this source and
pass it through to the connected serial device. The port num-
ber must be used by the application connecting to local TCP
socket.
• Execute Changes—Save and execute changes made on
this screen (Shown only after changes have been entered.)
Library Admin Office
Serial Gateway Configuration Menu
-==========================================================================-
Com2 Serial Data Port
A) Enable enabled F) Receive on Port 30011
B) Mode IP-to-Serial
C) Data Baud Rate 115200
D) Flow Control enabled
Select a letter to configure an item, <ESC> for the prev menu
