MDS 05-2806A01, Rev. A MDS iNET 900 User’s Guide 39
Invisible place holder
2.5.6 Mixed Modes
Note that the IP-to-Serial mode does not involve the Access Point. Thus
the iNETs in a single network can run in both modes at the same time.
In other words, some Remotes can be configured for IP-to-Serial mode
while others are configured, along with the Access Point, for the
Serial-to-Serial mode. In this configuration, the Host PC can use both
data paths to reach the RTUs. This may be helpful when a mixed collec-
tion of RTUs is present where some RTUs can operate in a broadcast
form while others cannot. (See Figure 2-19 and Table 2-4)
Table 2-3. Serial Port Configuration Example
iNET Unit Location Menu Item Setting
Access Point (COM2)
1
Enable Enabled
Mode Serial-to-Serial
Baud Rate 9600 (Example)
Flow Control X-ON/X-OFF (Example)
Send to Address 224.254.1.1—
Multicast Address
2
Send to Port 30011
Receive on Port 30011
Receive on Address 0.0.0.0
Seamless Mode Disabled
Delimiter Chars 0
Latency Chars 0
Remote Units (COM2)
1
Enable Enabled
Mode Serial-to-Serial
Baud Rate 2,400 (Example)
Flow Control Hardware (Example)
Send to Address 192.168.0.1
Send to Port 30011
Receive on Port 30011
Receive on Address 224.254.1.1 —
Multicast Address
2
Seamless Mode Disabled
Delimiter Chars 0
Latency Chars 0
1. Either COM port can be used, but they must be the same ones at
both ends of the link. Both COM ports can be used simultaneously
for two independent data channels.
2. This address is an example only. Any Class D IP address will work.
