b.Comments can be of any length, but must be on the same
line as the parameter, or on a new line that begins with a
semicolon character.
c.Comments after parameters included in files exported from
an iNET 900 unit do not need to be present in your cus-
tomized files.
• The number of blank spaces between the field name (left col-
umn) and the parameter value is not important.
2.11 OPERATING PARAMETERS’
DEFAULTS
The MDS iNET 900 can be monitored and configured through its
embedded management system as detailed elsewhere in this manual.
Below is a flowchart of the primary menu items of this system. The fol-
lowing pages will provide details on the defaults and range of acceptable
values. Note that a few menu items are only displayed when the iNET
unit is operating in the Access Point or Remote mode, and some will
require an Authorization Key.
Invisible place holder
Figure 2-39. Management System Menu Flowchart
NOTE: Items displayed on the MS start-up screen are not shown
.
User Password
Console Baud Rate
Device Names
Device Name
Owner
Contact
Description
Location
Date
Time
Date Format
Model Number
Serial Number
Hardware Version
Firmware Version
Uptime
NOTES
• Not all items are user configurable
• Some menu items depend on Device Mode
• Dotted lines indicate read-only items
• Basic configuration parameters are shown in boxes • RMT = Remote Only
• Use keyboard’s spacebar to make some menu selections • AP = Access Point Only
Network
Configuration
Radio
Configuration
Serial Gateway
Configuration
Device
Information Maintenance Diagnostic Tools
Performance
Information
RSSI by Zone
Event Log
Packet Statistics
Wireless Network
Status
(RMT)
Remote Listing (AP)
Endpoint Listing (AP)
Remote Perf.
Listing (AP)
RF Power Output
Signal-to-Noise
RSSI
Reprogramming
TFTP
Host Address
TFTP Timeout
Filename
Retrieve File
Image Verify
Image Copy
Active Image
Reboot Device
Configuration
Scripts
TFTP Host
Address
Filename
TFTP Timeout
Retrieve File
Send File
Authorization Key
Radio Test
Test Mode
Frequency
TX Output Power
TxKey
RSSI
Ping Utility
COM1 & COM2
Serial Data Port
Enable
Mode
Data Baud Rate
Flow Control
Send to Address
Sent to Port
Receive on Port
Receive on
Address
Seamless Mode
Delimiter Chars
Latency Chars
Serial Data
Statistics
STARTING INFORMATION SCREEN
MAIN MENU
RF Output
Power
Data Rate
Dwell Time
Beacon Period
Hop Pattern
Seed
(AP)
Fragmentation
Threshold
RTS Threshold
RSSI Threshold
SNR Threshold
Skip Zone Options
Device Mode
Network Name
IP Address
IP Netmask
IP Gateway
SNTP Server IP
DHCP Enable
SNMP Config.
Menu
Max. Allowed
Remotes
(AP)
Required AP (RMT)
Backup Network
Name (RMT)
Ethernet Address
Wireless Address
