32 MDS iNET 900 User’s Guide MDS 05-2806A01, Rev. A
NOTE: In the discussion that follows, COM1 and COM2 will be treated
alike unless noted. They provide essentially the same data
services.
Configuration
There are several configuration parameters for the Remote Serial
Gateway found under the Serial Configuration Menu of the iNET Man-
agement System. Note that some of the parameters are not applicable to
IP-to-Serial mode. After making changes to the configuration, you must
use the menu’s “Execute Changes” to cause the iNET to implement the
requested changes.
If you are connecting EIA-232 serial devices to the iNET unit, review
these parameters carefully.
2.5.2 Serial Gateway (Port) Configuration Menu
The first two menu items present the identical parameter fields for each
port. The third item—Serial Data Statistics—presents statistics for both
ports on one screen.
Figure 2-12. COM1/2—Serial Gateway (Port) Configuration Screen
• Com1 Serial Data Port—For additional information
Serial-to-Serial: See Page 35
IP-to-Serial: See Page 33
• Com2 Serial Data Port—
Serial-to-Serial: See Page 35
IP-to-Serial: See Page 33
• Serial Data Statistics—Provides statistics on the
serial and IP activity through the
COM1 and COM2 ports.
(See Page 35 for details)
Library Admin Office
Serial Gateway Configuration Menu
-==========================================================================-
A) Com1 Serial Data Port
B) Com2 Serial Data Port
C) Serial Data Statistics
Select a letter to configure an item, <ESC> for the prev menu
