MDS 05-2806A01, Rev. A MDS iNET 900 User’s Guide 41
2.6 PERFORMANCE VERIFICATION
After the basic operation of the radio has been checked, you may wish
to optimize the iNET 900 network’s performance using some of the fol-
lowing suggestions. The effectiveness of these techniques will vary with
the design of your system and the format of the data being sent.
There are two major areas for possible improvement—the radio and the
data network. The following sections will provide you with a variety of
items to check and on many occasions, ways to correct or improve their
performance.
2.6.1 Performance Information Menu
This menu/screen is one of two primary sources of information on the
radio layer and iNET network performance.
Figure 2-20. Performance Information Menu Screen
(Access Point Version Shown)
• RF Output Power (Display only)—Measured power output.
(See “How Much Output Power Can be Used?” on Page 103)
Remote Units 3 & 4 Enable Enabled
Mode Serial-to-Serial
Baud Rate 9,600
Flow Control None
Send to Address IP address of the iNET Access
Point
Send to Port 30011
Receive on Port 30011
Receive on Address The multicast IP address used
for the AP’s Send To Address
above
Table 2-4. Serial Port Configuration Example (Continued)
iNET Unit Location Menu Item Setting
Library Admin Office
Performance Information Menu
-==========================================================================-
RF Output Power 25 dBm
Signal to Noise AP
RSSI AP
A) RSSI By Zone D) Remote Listing
B) Event Log E) Endpoint Listing
C) Packet Statistics F) Remote Performance Listing
Select a letter to configure an item, <ESC> for the prev menu
