MDS iNET 900 - Diagnostic Tools Menu

MDS 05-2806A01, Rev. A MDS iNET 900 User’s Guide 51
2.6.2 Diagnostic Tools Menu
Figure 2-30. Diagnostic Tools Menu Screen
• Radio Test—Suite of tools for installers and maintainers.
(See “Radio Test Menu” on Page 51)
• Ping Utility—
PING any IP address within local LAN from
the iNET unit. (See “Ping Utility Menu” on Page 52)
Radio Test Menu
Figure 2-31. Radio Test Menu Screen
Shown with Test Mode Enabled
This area provides several useful tools for installers and maintainers.
You can manually key the iNET radio transmitter to make measure-
ments of antenna performance. (See “Antenna Direction Optimization”
on Page 93 for details.
Library Admin Office
Diagnostic Tools Menu
-==========================================================================-
A) Radio Test
B) Ping Utility
Select a letter to configure an item, <ESC> for the prev menu
Library Admin Office
Radio Test Menu
-==========================================================================-
A) Test Mode ON
B) Frequency 915.000000 MHz
C) TX Output Power 25 dBm
D) TxKey disabled
RSSI -67 dBm
Time Remaining 09:50
Select a letter to configure an item, <ESC> for the prev menu
