52 MDS iNET 900 User’s Guide MDS 05-2806A01, Rev. A
NOTE : Use of the test mode will disrupt traffic through this unit. If the
unit is the Access Point, it will disrupt traffic through the entire
MDS iNET 900 network.
Test Mode function is automatically limited to 10 minutes and
should only be used to measure transmit power. It may also be
manually reset to continue with the testing or turned off.
• Test Mode (ON/OFF)—Controls access to the iNET suite
of tools.
• Frequency—Set radio operating frequency during the test-
ing period to a single frequency.
• TX Output Power—Temporarily overrides the power
level setting in the Radio Configuration Menu.
• TxKey—Manually key the radio transmitter for power mea-
surements.
• RSSI—Incoming received signal strength on frequency
entered in the frequency parameter on this screen (–dBm).
This RSSI measurement is updated more frequently than the
RSSI by Zone display of the Performance Information menu.
Ping Utility Menu
Figure 2-32. Ping Utility Menu Screen
• IP Addr—Address to send a PING.
• Count—Number of PING packets to be sent.
• Packet Size—Size of each PING data packet (bytes).
• Go—Send PING packets to address shown on screen.
Screen will be replaced with detailed report of PING activity.
Press any key after viewing the results to return to this menu.
Library Admin Office
Ping Utility Menu
-==========================================================================-
A) IP Addr 192.168.1.1
B) Count 4
C) Packet Size 32
D) Go
Select a letter to configure an item, <ESC> for the prev menu
