MDS 05-2806A01, Rev. A MDS iNET 900 User’s Guide 29
• SNMP Config Menu (Telnet/Terminal Only)—SNMP configu-
ration parameters.
• Required AP (
Remote Only)—IP address of only Access Point
with which, this unit is permitted to associate.
• Backup Network Name (
Remote /Read-Only)—Network Name
of back up Access Point unit to be used whenever the desired
Access Point beacon signal is lost.
• Maximum Allowed Remotes
(Access Point Only)—Number of
iNET Remotes permitted to be associated with (served by) this
Access Point.
• Ethernet Address
(Display Only)—Hardware address of this
unit’s Ethernet interface.
• Wireless Address
(Display Only)—Hardware address of the
unit’s wireless interface.
2.4 CONFIGURING RADIO
PARAMETERS
There are two primary data layers in the MDS iNET 900 network—
radio and data. Since the data layer is dependent on the radio layer
working properly, this is a good place to make sure the unit is configured
as you want it to be. This is the primary radio menu, the Radio Config-
uration Menu, and a secondary menu, the Skip Zone Options.
2.4.1 Radio Configuration Menu
Figure 2-10. Radio Configuration Menu Screen
• RF Output (User Review Recommended)—Set RF power output
level. Displayed in dBm. Setting should reflect local regulatory
limitations and losses in antenna transmission line. (See “How
Much Output Power Can be Used?” on Page 103 for informa-
tion on how to calculate this value.)
Library Admin Office
Radio Configuration Menu
-==========================================================================-
A) RF Output Power 30 dBm F) Fragmentation Threshold 1600 bytes
B) Data Rate 256 kbps G) RTS Threshold 1600 bytes
C) Dwell Time 32.8 msec H) RSSI Threshold 60 dBm
D) Beacon Period 52 msec I) SNR Threshold 20 dB
E) Hop Pattern Seed 14 J) Country USA
K) Skip Zone Options
Select a letter to configure an item, <ESC> for the prev menu
