68 MDS iNET 900 User’s Guide MDS 05-2806A01, Rev. A
Tables of iNET Management System Menus
Menu Table of Parameters Description of Screen
Network Configuration Table 2-7 on Page 68 Network Configuration Menu on
Page 28
Radio Configuration Table 2-8 on Page 68 Radio Configuration Menu on Page 29
Serial Configuration
(COM2)
Table 2-9 on Page 69 Serial Gateway (Port) Configuration
Menu on Page 32
Device Information Table 2-10 on Page 70 Device Information Menu on Page 26
Performance Information Table 2-11 on Page 71 Performance Information Menu on
Page 41
Diagnostics Tools Table 2-13 on Page 72 Diagnostic Tools Menu on Page 51
Table 2-7. Network Configuration Menu Structure and Functions
Submenu Description Default Acceptable Range
Device Mode Operational mode of the
iNET
Remote Remote, Access Point
Network Name Text name for the iNET
network
“Not Programmed” Any 15-character
alphanumeric string
IP Address IP address of the iNET 192.168.1.1 Any legal IP address
IP Netmask IP netmask of the iNET 255.255.0.0 Any legal subnet mask
IP Gateway IP gateway of the iNET 0.0.0.0 Any legal IP address
SNTP Server IP Server providing day and
time information
0.0.0.0 Any legal IP address
DHCP Enable Service that provides
on-the-fly IP address to the
iNET
Disabled Enabled, Disabled
Maximum Allowed
Remotes
Total number of Remotes
allowed to associate w/
Access Point
50 1 to 255
Ethernet Address Ethernet Address of the
iNET
Specific to unit –
Wireless Address MAC address of the iNET Specific to unit –
Table 2-8. Radio Configuration Menu Structure and Functions
Submenu Description Default Acceptable Range
RF Output Power
Setpoint
Desired Output Power value 30 dBm 20 - 30 dBm
Data Rate The over-the-air data rate of
the radio
256 256 kbps
512 kbps
Dwell Time Length, in time, of one hop
on a particular frequency
32.8 msec 16.4, 32.8, 65.5, 131.1,
262.1 msec
Beacon Period Amount of time between
Beacon transmissions
100 msec 50 to 1000 msec
50, 104, 208, 508
Recommended
Hop Pattern Seed A random value used to
seed the freq hopping
algorithm
1 1 to –65,000
