TROUBLESHOOTING -- EZ-CAL ADJUSTMENTS
EZ-C AL A DJUSTMENTS
Refer to "Using the EZ-Cal Scan Tool" on page 4-8.
Adjustments are possible only in Access Level 1.
Before changing personalities, ensure that the Correct Customer and Model have been
selected in the SETUPS menu. Any changes to settings will be lost when the model or
customer is changed.
To reach ADJUSTMENTS, first access Level 1, then press --> for ADJUSTMENTS.
Press Enter, then press --> to scroll through the sub-menus.
Once the desired sub-menu is found, press Enter again, then --> to scroll through the
personalities. Press the Up or Down arrows to change the personality. Press ESC to go
back one or more levels to reach other sub-menus.
EZ-C AL S ETUP
Only authorized personnel may have access to and may make changes to
personalities.
The Setups Menu is where machine and model settings may be changed. It is also the
location where calibrations are performed.
Refer to "Using the EZ-Cal Scan Tool" on page 4-8.
EZ-C AL D IAGNOSTICS
The EZ-Cal Diagnostics menu provides the ability to view and test individual circuits for
irregularities. Whether diagnosing a failure or testing functions during preventative mainte-
nance, the Diagnostics Menu provides a quick view at the inputs and outputs as registered
by the GP400 Control Module in real time.
To reach DIAGNOSTICS menu from HELP;
• Press the right arrow and scroll to DIAGNOSTICS and press ENTER.
• Locate the desired sub menu and press ENTER.
• Press the right arrow to scroll through the test points.
NOTE: The ID number will not appear on the EZ-Cal display. It is shown in the Diagnostics Menu for reference only.
Press ESC to go back one level (necessary to change selection).
