Mec 4069RT - Functions Manifold, 2

March 2014
Page E-7
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Functions Manifold, 2 of 2
ITEM PART NO. QTY DESCRIPTION
-- 93145 -- Functions Manifold Assembly, without fittings
1 91151 3 Pilot-Operated Valve
2 91143 9 Coil
3 93502 2 Solenoid Valve, Rear Wheel Bypass
4 91152 2 Pilot-Operated Valve
5 91477 2 Check Valve
6 92173 3 Coil
7 91464 1 Solenoid Valve, Rear Wheel Bypass
8 93501 1 Orifice Disc, .060
9 91147 2 Solenoid Valve, High Torque/High Speed
10 93496 2 Solenoid Valve, Drive
11 91008 2 Solenoid Valve, Outrigger & Steering Directional
12 91015 1 Hand Pump
13 93497 1 Relief Valve
14 91145 1 Solenoid Valve, Lift
15 91009 1 Relief Valve
16 91012 1 Manual Brake Releas
e Valve
17 93494 2 Flow Divider
18 93500 2 Orifice Plug, .025
19 93493 1 Check Valve
20 93503 2 Counterbalance Valve
21 93499 1 Shuttle Valve
22 93495 1 Orifice Plug, .063
23 93498 1 Flow Regulator
