March 2014
Page E-3
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hydraulic Components
ITEM PART NO. QTY DESCRIPTION
1 89013 1 Hydraulic Reservoir
2 93145 1 Functions Manifold
3 21273 1 Upper Lift Cylinder
4 21272 1 Lower Lift Cylinder
5 92974 4 Wheel Motor/Brake Unit
6 91160 1 Hydraulic Pump
7 21398 2 Steer Cylinder
8 93031 4 Option -- Outrigger Cylinder
9 93280 1 Proportional Valve
