“4069RT” Parts Section
Wiring Harness Components
Harness plug designations (J#) and components listed in parentheses correspond to locations listed on the
Electrical Schematics. See Section 5 of the Service portion of this manual.
ITEM PART NO. QTY DESCRIPTION
1 21629 1 Harness, Lower Control Box Interior (Interior of Lower Control Box, J1, J2)
2------
3 21630 1 Harness, Main Chassis (J1, J3, J4, J5, J6, J7, Functions Manifold)
4
92222 1 Harness, Diesel Engine
92136 1 Harness, Dual Fuel Engine
5 21623 1 Harness, Communication Cable (J4, J8)
6 91780 1 Harness, Platform (J8, J9)
7 91761 1 Harness, Upper Control Box Interior
8
9441 71 ft.
Cable, Power To Platform (Plu
g at rear of Controls Module, Outlet at platform)
This length also used to power platform work lights
93251 75 ft. Cable, Power To Platform, Arctic (Plug at rear of Controls Module, Outlet at platform)
9 21633 1 Elevating Assembly Harness (J5, Transducers, Down valves)
10 21631 1 OPTION -- Outrigger Harness (J6, J7, Outriggers)
11 91293 1 Harness, Joy
stick
