“4069RT” Service and Parts Manual March 2014
Page 2-17
GP400 CONTROL MODULE SETUP
GP400 C ONTROL M ODULE S ETUP
L OCATION
• The GP400 Control Module processor is located in the lower control box.
• The Matrix Module is located in the upper control box.
Diagnostic information can be found in Section 4: Troubleshooting.
Wiring information can be found in Section 5: Schematics.
Figure 2-19: Module Locations
ART_3156
GP400
Control Module
GP400
Matrix Module
Diagnostic LED
Lower ControlsUpper Controls
Terminal
Block
Module
