Mec 4069RT - Wheel Motors & Steering Yoke Components

March 2014
Page D-5
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Wheel Motors & Steering Yoke Components
ITEM PART NO. QTY DESCRIPTION
1 21353 1 Hose Guard, Right Side
2 21344 1 Steering Yoke, Right Side
3 50033 4 Bolt, M10 x 25
4 50006 36 Washer, M10 Nordlock
5 26057 4 King Pin Weldment
6 50439 32 Bolt, M10 x 50 Socket Head
7 21345 1 Steering Yoke, Left Side
8 92360 4 Bearing
9 REF 4 Motor/Hub Assembly -- See Section E
10 92341 2 Thrust Washer
11 50048 2 Nut, M8 Nylock
12 92787 2 P-Clamp
13 21354 1 Hose Guard, Left Side
14 50031 4 Bolt, M8 x 25
15 50001 4 Washer, M8 Std
16 50025 2 Bolt, M8 Carriage
