March 2014
Page A-3
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Platform Controls
ITEM PART NO. QTY DESCRIPTION
-- 89058 -- Assy, Upper Control Box - RT - ANSI - No Options
-- 89059 -- Assy, Upper Control Box - RT - ANSI - With Outriggers
-- 89060 -- Assy, Upper Control Box - RT - ANSI - With Horn
-- 89061 -- Assy, Upper Control Box - RT - ANSI - With Outriggers + Horn
-- 89079 -- Assy, Upper Control Box - RT - CE - No Options
-- 89080 -- Assy, Upper Control Box - RT - CE - With Outriggers
-- 89083 -- Assy, Upper Control Box - RT - CE - GSE -
1 HDW90803 2 Nut
2 HDW90879 2 Scr
ew
3 91663 1 Matrix Module
4 7553 1 Optional Overload Sensing System -- Alarm, Overload Warning
5 6234 1 Switch, Toggle, 2-Position
6
9184 1 Std. Machine -- Lens, Amber, Tilt Indicator
9183 1 Optional Overload Sensing System -- Lens, Red, Overload Indicator
9188 1 Light, Bayonet, 14 Volt
9179 1 Socket, Indicator Light
7 6905 1 Switch, Toggle, 3-Position
8 7800 1 Switch, Emergency Stop
9 91619 1 Switch, Start
10 5630 1 Switch, 2-Position Momentary
11 -- -- --
12 8044 1 Switch, Horn Button (Option)
13 90789 1 LED, Gr
een, Drive Enabled (outrigger-equipped machines)
14 5694 1 Switch, Toggle (outrigger-equipped machines)
15 16242 1 Weldment, Control Box
16 13865 1 Bracket, Control Box Holder
17 6350 0.5 FT Tape, Foam
18 HDW5724 1 Screw, 5/16–18
19 13864 1 Bracket, Control Box Holder
20 50350 1 Washer, Flat
21 8826 1 Thumb Screw, 5/16–18, Flower
22 REF 1 Harness, Removable (See Wire Harness, Section F)
23 REF 1 Cable, Removable (See Wire Harness
, Section F)
To Next Page
