March 2014
Page B-5
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Main Platform
ITEM PART NO. QTY DESCRIPTION
1 21386 2 Side Rail
2 21373 1 Main Platform Weldment, withou t deck plate
-- 21389 1 Main Platform Deck Plate
3 50512 2 Bolt, 5/8 x 3.25
4 50398 2 Nut, 5/8 Nylock
5 87125 2 Roller
6 26564 1 Lock Plate
7 50030 5 Bolt, M8 x 20
8 50048 5 Nut, M8 Nylock
9 26566 2 Corner Brace
10 21391 1 Right Side Rear Rail
11 91888 2 Hinge
12 19239 4 Backup Plate
13 26342 1 Personnel Gate, without toe board
-- 26347 1 Gate Toe Board
14 92836 1 Gate Latch
15 21390 1 Left Side Rear Rail
16 50182 10 Spring Clip
To Next Page
