Mec 4069RT - Hoses - Drive Circuit, Front Wheels

March 2014
Page E-31
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hoses -- Drive Circuit, Front Wheels
ITEM
PART
NUMBER
QTY. DESCRIPTION HOSE NAME
1 52444 2 Hose Assy, 1/2 x 36 inch, 08G-08FFORX -08G-08FFORX90S D-LF-B-BH/RF-A-BH
2 52445 1 Hose Assy, 1/2 x 33 inch, 08G-08FFORX -08G-08FFORX90S D-RF-B-BH
3 51112 4 Fitting, MFFOR-MB45-8-8 Bulkhead
4 52448 2 Hose Assy, 1/2 x 80 inch, 08G-08FFORX -08G-08FFORX D-RF-B-MF
5 52443 1 Hose Assy, 1/2 x 31.5 inch, 08G-08FFORX -08G-08FFORX90S D-LF-A-BH
6 52447 1 Hose Assy, 1/2 x 55.5 inch, 08G-08FFORX -08G-08FFORX D-LF-A-MF
7 52446 1 Hose Assy, 1/2 x 55.5 inch, 08G-08FFORX -08G-08FFORX45S D-LF-B-MF
