Mec 4069RT - Hoses - Outrigger Circuit

March 2014
Page E-39
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hoses -- Outrigger Circuit
ITEM
PART
NUMBER
QTY. DESCRIPTION HOSE NAME
1 52474 2 Hose Assy, 1/4 x 43.75 inch, 04G-04FFORX-04G-04FFORX90S ORR-R-A/B
2 52458 2 Hose Assy, 1/4 x 17.5 inch, 04G-04FFORX-04G-04FFORX ORR-L-A/B
3 52472 1 Hose Assy, 1/4 x 59 inch, 04G-04FFORX-04G-04FFORX90S ORR-A
4 52456 2 Hose Assy, 1/4 x 86 inch, 04G-04FFORX-04G-04FFORX ORF-B/A
5 52471 1 Hose Assy, 1/4 x 61.25 inch, 04G-04FFORX-04G-04FFORX90S ORR-B
6 52457 2 Hose Assy, 1/4 x 20.5 inch, 04G-04FFORX-04G-04FFORX ORF-L-A/B
7 52473 2 Hose Assy, 1/4 x 40 inch, 04G-04FFORX-04G-04FFORX90S ORF-R-A/B
81Hose Assy, 1/4 x 6 inch, 04G-04FFORX-04G-04FFORX90S OR RET
9 50809 3 Fitting, MFFOR-FFORX-MFFOR-4
10 51074 1 Fitting, FFORX-MB90-4-4
11 51137 1 Fitting, MB-FB-6-4
12 93288 1 Relief Valve Assembly
13 51127 1 Fitting, MB-MFFOR-6-4
