March 2014
Page A-5
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Upper Control Box Cover Assembly
ITEM PART NO. QTY DESCRIPTION
1 83076 1 Control Box Cover Assembly
2 92199 1 Joystick Assembly
3 3772 1 Cover
4 7875 1 Gasket
5 7882 1 O-Ring
6 HDW3768 1 Washer, Flat
7 1008348 1 Pin, Hold Down
8 50155 1 Screw, 6–32 x 1/2 inch
9 13502 1 Bracket, Centerin g
10 3763 1 Spacer, Step
11 13402 1 Gear, large
12 HDW8531 2 Washer, Flat
13 HDW7881 1 Washer, Bevel
14 3782 1 Cam, Directional
15 13403 1 Plate, Bottom
16 6917 1 Clamp, Cable, 1/4 inch
17 7818 1 Bearing, Bronze, Flanged
18 HDW3771 1 Washer, Flat
19 5736 1 Ring, Retainin
g, 1/2 inch
20 50139 4 S crew, 4-40 x 5/8 inch
21 -- -- --
22 -- -- --
23 -- -- --
24 50191 12 Screw, 10–32 x 1/2 inch
25 3764 2 Plate, Spacer
26 8696 2 Switch, Limit, Micro V7
27 3765 2 Plate, Strap
28 3766 1 Plate, Top
29 7819 1 Bearing, Bronze, Flanged
30 8435 1 Spring, Joystick Centering
31 91824 1 Potentiometer Assembly
32 REF 1 Wire Harness, (see Wire Harness, Section F)
To Next Page
