Mec 4069RT - Hoses - Brake Circuit

March 2014
Page E-35
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hoses -- Brake Circuit
ITEM
PART
NUMBER
QTY. DESCRIPTION HOSE NAME
1 52462 1 Hose Assy, 1/4 x 79 inch, 04G-04FFORX-4G-4FFORX 45 RF-BRK
2 50878 2 Fitting, MFFORT-4
3 52464 1 Hose Assy, 1/4 x 45 inch, 04G-04FFORX-4G-4FFORX 45 RR-BRK
4 52461 1 Hose Assy, 1/4 x 73.5 inch, 04G-04FFORX-4G-4FFORX 45 LF-BRK
5 50864 1 Fitting, MFFOR-MFFOR-FFORX-4
6 52468 1 Hose Assy, 1/4 x 30 inch, 04G-04FFORX-04G-04FFORX90S R-BRK-CROSS
7 52463 1 Hose Assy, 1/4 x 48.5 inch, 04G-04FFORX-4G-4FFORX 45 LR-BRK
8 52465 1 Hose Assy, 1/4 x 22 inch, 04G-04FFORX-4G-4FFORX 45 MF-T-BRK
