Mec 4069RT - Upper Control Joystick

March 2014
Page A-7
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Upper Control Joystick
ITEM PART NO. QTY DESCRIPTION
-- 92199 -- Joystick Assembly
-- 8630 -- Joystick Assembly without Control Arm (#6)
1 8750 1 Pin
2 8453 1 Switch Actuator
3 HDW8455 4 Screw
4 8752 1 Grip, Top Half
5 8751 1 Grip, Bottom Half
6 13638 1 Control Arm without wire
7 8748 1 Trigger
8 8456 1 Rocker Boot
9 8447 1 Switch Separator
10 8753 1 Motion Switch, OFF-ON
11 8448 2 Switch
12 91839 3 Amp Socket
13 92194 1 Push Connector, 3/16"
14 92198 1 Adapter, 2-to-1
-- 8761 -- Switch Assembly (not shown) -- incl
udes item #9, item #11 (x2), wire and connectors
