March 2014
Page D-7
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Steering Components
ITEM PART NO. QTY DESCRIPTION
1 50433 2 Shoulder Bolt, M16 Thread Socket Head, M20 x 60 Shoulder
2 93044 2 Bronze Bearing
3 21337 1 Tie Rod
4 17491 2 Clevis Pin
52Shoulder Bolt, 3/4" thread, 1 x 4 shoulder
6REF2Steering Cylinder Assembly -- See Section E
7 21344 1 Steering Yoke, Right Side
8 17492 2 Pin Clip
9 21345 1 Steering Yoke, Left Side
To Next Page
