March 2014
Page A-9
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Base Controls
ITEM PART NO. QTY DESCRIPTION
-- REF -- Harness -- See Section F
1 9549 1 Switch, 3-Position, Keyed
2 91667 3 Switch, Button, Green
3 7800 1 Switch, Emergency Stop
4 91704 1 Hour Meter
5 92254 1 Light, Red
6 91957 1 Switch, Button, Black
7 7235 1 Circuit Breaker
8 5630 1 Switch, Toggle, 1 Pole 2 Position, Emergency Down
9 1313 1 Switch Guard
10 91659 1 S ystem Controller, GP400
11 50229 6 S crew, 10-24 x 1.00
12 50230 6 Nut, 10-24 Nylock
13 91887 1 Deutsch Co
nnector, DRC 12 70P
14 50233 6 S crew, 8-32 x 1.00
15 50231 6 Nut, 8-32 Nylock
16 8082 6 Contact Block, N. O.
17 90714 6 Contact Base
18 91711 1 Alarm, 107dB
19 17082 1 Bracket, Alarm Mount
20 91838 1 Terminal Block Module (TBM)
21 91290 1 Deutsch Connection, DT14-4P-L012
22 92016C 1 Control Box
23 91921 1 Lanyard
