March 2014
Page B-7
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Deck Extension
ITEM PART NO. QTY DESCRIPTION
1 26348 1 Right Side Rail Weldment
2 50020 3 Bolt, M10 x 50
3 50049 5 Nut, M10 Nylock
4 50028 4 Bolt, M6 x 20
-- 50000 4 Washer, M6 std.
-- 50047 4 Nut, M6 Nylock
5 21394 1 Front Rail Weldment
6 8909 1 Manual Box
7 50022 2 Bolt, M10 x 70
8 26560 1 Extension Handle
9 26433 1 Extension Release Bar
10 26352 1 Left Side Rail Weldment
11 50182 4 S pring Clip
12 21374 1 Deck Extension Weldment, without deck plate
-- 21466 1 Deck Extension Deck Plate
13 50048 4 Nut, M8 Nylock
14 50397 2 Bolt, 5/8 x 4.5
15 26239 2 Deck Release Guide
16 26326 1 Deck Release Weldment
17 92866 2 S pring
18 50418 4 Carriage Bolt, M8 x 25
19 50004 2 Washer M16 S
td.
20 87125 2 Roller
21 50398 2 Nut, 5/8 Nylock
22 87124 2 Roller
23 26450 2 Pin
To Next Page
