March 2014
Page B-17
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
OPTION -- GSE Main Platform, 2 of 2
ITEM PART NO. QTY DESCRIPTION
1 21593 2 Bumper, Long
2 21595 2 Bumper Weldment
3 21599 3 Bumper, Short
4 91888 4 Hinge
5 21594 1 Gate Post
6 21598 1 Bumper Weldment
7------
8 87125 2 Roller
9 21587 1 Right Side Gate Assembly
10 21588 1 Left Side Gate Assembly
11 21585 1 Gate Weldment, Right
12 -- -- --
13 8909 1 Manuals Box
14 21580 1 Gate Stopper, Right
15 21579 2 Gate Latch Bracket
16 92302 1 Gate Latch, Right
17 50375 4 Bolt, M6 x 30 Button Head
18 50047 16 Nut, M6 Nylock
19 50000 28 Washer, M6 Std.
20 50262 8 Bolt, M6 x 50
21 50294 4 Bolt, M6 x 45
22 21586 2 Gate Toe Board
23 21589 1 Gate Stopper, Left
24 92251 1 Gate Latch, Left
To Next Page
