Mec 4069RT - Page 167

March 2014
Page C-3
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Scissor Assembly
ITEM PART NO. QTY DESCRIPTION
1
21420 1 Standard Machine -- Scissor Beam
21557 1 GSE Spec/Centered Platform Machine -- Scissor Beam
2
21421 1 Standard Machine -- Scissor Beam
21558 1 GSE Spec/Centered Platform Machine -- Scissor Beam
3 21419 1 Scissor Beam
4 21418 1 Scissor Beam
5 21416 1 Scissor Beam
6 21417 1 Scissor Beam
7 21414 1 Scissor Beam
8 21415 1 Scissor Beam
9 21413 1 Scissor Beam
10 21412 1 S cissor Beam
11 21422 4 Cylinder Mount Weldment
12 21288 2 Beam
Support Weldment
13 REF 1 Upper Lift Cylinder -- See Section E
14 REF 1 Lower Lift Cylinder -- See Section E
15 21467 1 Maintenance Lock
16 6701 15 Retaining Ring
17 HDW13175 25 Washer, Nylon
18 25429 16 Rubber Spacer
19 50236 4 Bolt, M12 x 40
20 18152 4 Pin Retainer
21 21472 4 Cylinder Pin
22 9587 2 Lower Slide Pad
23 7160 2 Bearing
24 40301 2 S lide Casting
25 90235 2 Upper Slide Pad
26 30407 1 Pin
27 26449 4 Platform Block
