March 2014
Page E-9
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hydraulic Reservoir
ITEM PART NO. QTY DESCRIPTION
-- 89013 -- Hydraulic Reservoir, Complete as shown
1 21355 1 Tank Weldment
293701Sight Gauge
3 51006 1 Plug, 3/8 NPT
4 92335 1 Cap
5 50034 4 Bolt, M10 x 30
6 50002 4 Washer, M10 std.
7 92565 1 Filter Assembly
-- 92924 -- Filter Element
8 50664
3 Early Machines --Fitting, MP-MJ-4-4
2 Later Machines -- Fitting, MP-MJ-4-4
9 92569 1 Suction Strainer
10 51004 1 Fitting, MB-HB90-12-16
11 HDW6727 1 Fitting, 1/4 NPT, 5/16 Barb
To Next Page
