March 2014
Page F-3
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Control Module
ITEM PART NO. QTY DESCRIPTION
1 91539 1 Alarm
2 21462 1 Brace
3 19271 1 Bracket
4 REF 1 Lower Controls -- See Section A
5 8386 1 Door Latch
6 21333 1 Controls Module Door
7REF1Hydraulic Tank -- See Section E
8REF1Functions Manifold -- See Section E
9 21496 1 Battery Hold-Down
10 22563 2 J-Bolt
-- HDW6110 2 Wing Nut
11 17966 1 Battery
12 14896 1 Door Slide Block
13 8841 1 Switch, Batter y Cutoff
14 90749 1 Plug, Power To Platform
To Next Page
