March 2014
Page F-21
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Ladders
ITEM PART NO. QTY DESCRIPTION
1 21338 1 Ladder Weldment, Standard
2 50250 4 Bolt, M12 x 50
3 50003 4 Washer, M12 Std
4 50050 4 Nut, M12 Nylock
5 21533 1 Ladder Weldment, GSE Option
