Oil Pan and Oil Pump
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Oil pan
2 1 Oil drain plug 24 – 17.7
3 1 Oil pan gasket
4 1 Screw 24 – 17.7
5 1 U‑clamp
6 12 Oil pan screw 35 – 25.8
7 1 Oil pump
8 1 Oil pump screw
First
torque
20 177 –
Final
torque
+ 65º
9 1 Retainer
10 1 Oil pump shaft
11 1 Oil pump drive
12 1 Dipstick
13 1 Dipstick tube
14 1 Dipstick tube screw 11.5 101.8 –
15 1 Screw 30 – 22.1
Engine Disassembly
