Remote Oil Filter
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Remote oil filter housing
2 1 Fitting
3 1 Oil filter
4 4 O‑ring
5 2 Screw, M10 x 16
6 1 Oil filter to block oil line
7 1 Bracket
8 2 Screw, M6 x 12 31.1 – 22.9
9 1 Oil cooler to filter oil line
10 1 Bracket
11 2 Screw, M6 x 12 31.1 – 22.9
12 1 Block to cooler oil line
13 3 Screw, M8 x 16
14 1 Bracket
Engine Disassembly
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 3A-21
